Electric pivot door opener
$395-425
Intelligent control and automatic direction identification, smart multi operators linkage, push to open and precise positioning.
Motorized pivot doors
An electric pivot door, also known as an automatic pivot door or powered pivot door, is a type of door that is designed to pivot open and closed automatically using an electric motor or mechanism. Unlike traditional hinged doors that swing on hinges along one side, pivot doors rotate on a central axis, allowing them to open in a unique and stylish manner.
Smart push start
Each door can operated independently. Manually push one ofthem, and the door leaf rotates in the direction of pushing.
Other linked doors do not start, so that users can open the door at will, enhancing the user experience.
Precise positioning
Precise positioning
The perfect combination ofmechanical and electric. All door leaves can be accurately positionedon the same zero postion when closed.
Intelligent control and automatic direction identification
Ergonomic design, automatically identifies the walking, direction, adjusts the opening direction ofthe system.
Intelligent multi operators linkage
Multiple doors can be opened and closed synchronously to provide rapid traffic capacity
Product name | Electric pivot door | |||
Door Type | Single/Double/Multiple | |||
Input voltage | AC110 ~ 240V、50/60HZ | |||
Rated power | 80W | |||
Opening time | 3 ~ 12S (Adjustable) | |||
Hold open time | 0 ~ 30S (Adjustable) | |||
Closing time | 3 ~ 12S (Adjustable) | |||
Sensitivity | ＜ 100N (Adjustable) | |||
Door weight | ≤ 150kg | |||
Temperature | -30° C ~ 50° C | |||
Door width | 700-2000mm | |||
Manual open force | ≤ 10N | |||
Durable | ＞ 500，000 cycles | |||
Life Exectance | 5 Million Time | |||
Caelus servo motor | Traditional automatic door | |
life | No reduction gearbox design, small motor wear and more Heavy protection, longer service life | The gears of the reduction box are very easy to wear and the maintenance cost is high. The motor has a limited number of times and a short service life. |
Install | ① Quick installation components, easy to install ② Self-learning and adapting to the best state when powered on status, fool-proof installation is easier | ① The mechanical hardware structure is complex and the installation steps trouble ② The installation and debugging procedures are cumbersome and technically difficult |
Energy saving | ★Small mechanical friction ★ low loss ★low power ★ high energy efficiency | ★Mechanical friction is large ★ power and loss are high ★Low energy efficiency |
Caelus servo motor | Traditional automatic door | |
Safety | ★Anti-pinch systemincluded ★High-performance power supply to prevent short circuit, overvoltage and overcurrent faults and eliminate hidden dangers | Old-fashioned square wave control is insensitive and kinky Force driven, anti-pinch function may cause loss of control and injury. |
Stablize | ★ Vector control system, smooth operation ★ Tens of thousands of aging tests, low failure rate, 3 million+ of cycle operation without failure Adaptive and self-adjusting operating curve keeps the door in optimal operating condition. | ① Old-fashioned square wave control has poor accuracy and is easy to Stuttering occurs ② Complex structure and many fault points ③Mechanical wear and long-term use are prone to transportation problems. line error, requiring frequent manual adjustment and maintenance |
Function | ★ Supports rich personalized settings such as operating speed, door opening and closing time, etc. ★Supports free switching between automatic, inching, fully open, fully closed and other modes | The functional system is limited and backward, and the function settings are relatively Less, inconvenient to operate |
- Automatic Operation: Electric pivot doors are equipped with an electric motor or automation system that controls their movement. This allows for hands-free operation, making them convenient for high-traffic areas, commercial buildings, or spaces where manual operation may be impractical.
- Pivot Hinge: These doors pivot on a central hinge point, which can be located either at the top and bottom or at the center of the door. This design allows for larger and heavier doors to be easily operated, as the weight is evenly distributed along the pivot point.
- Modern Design: Electric pivot doors are often used in modern architectural designs to create a dramatic and impressive entrance. Their unique pivoting motion adds a sense of elegance and sophistication to the building’s appearance.
- Security: Many electric pivot doors come with advanced security features, such as access control systems, sensors, and locking mechanisms, to enhance building security.
- Customization: These doors can be customized in terms of size, materials, and finishes to suit the specific design and aesthetic preferences of a building or space.
- Energy Efficiency: Some electric pivot doors are designed with energy-efficient features, such as automatic closing to maintain indoor temperature control and reduce energy consumption.
- Accessibility: Automatic pivot doors can be designed to comply with accessibility standards, making them suitable for public buildings and spaces where accessibility is important.
Electric pivot doors are often used in upscale residences, commercial buildings, hotels, and other architectural projects where a grand and unique entrance is desired. They combine functionality with aesthetics and can create a lasting impression on visitors.
